AIRMEXT air suspension

AIRMEXT/SN125200BC3-DT2 (M52*1.5-50) /Dia.125mm rear air suspension airspring Double convolute/pneumatic parts/air suspension

stars, based on 0 reviews
$90.00 piece
1000items available
Contact Us
product details(ok)

This is new top grade air bellows type SN125200BC series

Fit for D2 coilover:

Damper Thread: M52*1.5
Body sealing part :50mm
Top: 12mm inner sealing



Following are REF pic of other brand:
A0F7EE420B2E58D82F2843EE513E5AF8
IMG_1477(1) IMG_1479(1) IMG_1480(1) IMG_1481(1) IMG_1483(1) IMG_1484(1) IMG_1486(1)

HTB1.GB1HpXXXXcWXpXXq6xXFXXXGHTB1DDQNHXXXXXccXXXXq6xXFXXXnHTB1rFUPHXXXXXaoXXXXq6xXFXXXpHTB1pkx0HpXXXXawXXXXq6xXFXXXt







Brand Name:
AIRMEXT
Type:
Air Pressure
Material Type:
steel
Item name:
SN125200BC3 series (Coilover fitted air spring)
Rubber bellows material:
PCBR
end plates:
Stainless steel
OEM / ODM:
yes
outer Dia. /Max Dia. at 110PSI:
125mm / 140mm
Max Dia. at 0.7Mpa working pressure:
140mm
Natural height&Max Height&Min height:
200mm&245mm&85mm
air inlet:
1/8NPT
Sealing Design:
Double inner sealing
Top:
12mm inner sealing
Thread dimension:
M52*1.5-50/M12
Fit:
D2 coilover
